Structural Steel Detailing

We provide high-precision 3D modeling and shop drawings that comply with AISC (USA), CISC (Canada), and Australian standards, ensuring seamless fabrication and erection for structural steel projects.

Our Process & Services:

• Standards Compliance – Adhering to AISC, CISC, and Australian standards to ensure quality, accuracy, and compliance with industry regulations.
• Multi-Discipline Coordination – Collaborating with architectural, mechanical, and structural teams to ensure smooth integration of steel detailing with other engineering disciplines.
• 3D Modeling & Detailing – Developing fabrication-ready 3D Tekla models with accurate member placement, connections, and material specifications.
• Erection & Fabrication Drawings – Delivering detailed shop and erection drawings for seamless assembly, fabrication, and installation.
• Clash Detection & Error Minimization – Using advanced clash detection tools to identify and resolve issues early, reducing rework and delays.
• CNC Fabrication Support – Generating precise CNC files and reports for automated fabrication, ensuring manufacturing efficiency and accuracy.
